What's structure of the large silo?
Come From:Taian Shelley Engineering Co., Ltd.Release Time:2015-9-29 20:35:20 Views:
Large storage body is composed of steel silo library library roof, wall and plate steel library library library library at the end of three parts.

      Large storage body is composed of steel silo library library roof, wall and plate steel library library library library at the end of three parts.
     1, the top plate library database
     Libraries Libraries steel roof is a hemispherical body, the lower and welded steel plate attached to the library.

     2, a large steel warehouse body
     Libraries Libraries are welded steel wall thickness ranging from steel plate, steel plate welded junction library library cylindrical wall thickness of the steel sheet used in the library 1-3 million tons of steel a bottom-up respectively 16, 14, 12,10,8,6mm; 5-20 tons of steel library is bottom-up, respectively 22,20,18,16,14,12,10,8mm, on the inside wall of the library has reinforced the link system, the entire library wall and steel reinforcement system link library into a whole.

     3, a large silo discharge system
     Library steel discharge system consists of gas pipelines, exhaust pipes, library gasification pipe, and a discharge passage of five parts.
